Grass feed |
Maize feed |
| Working speed |
Up to 18 km/h |
Up to 12 km/h |
| Depending on the header device and the growth |
| Penetration width |
560 mm |
| Chaff knife |
5 |
10 |
|
|
|
| Adjusting the length of the cut |
stepless |
stepless |
| Electrically adjustable through control element in the tractor |
|
|
| Chaff lengths |
From 8 – 36 mm |
From 4– 18 mm |
| Corn shredding |
“Mastercracker 250″ System for series lines |
| Working width |
440 mm |
| Re-shredding |
Actual cracker gap 1,150 mm |
| How it works |
Two rollers, moving in opposite directions, with convex and concave |
| 40 mm wide tools (250mm diameter) |
| (can be replaced individually) |
| Metal detector |
For series production |
| Automatic central lubrication unit |
For series production |
| Automatic grinding assembly |
For series production |
| Operations can be controlled through a |
| multifunctional level in series production |
| Can Bus System |
For all control functions and operations |
|
RPM monitor for Cracker |
|
Automatic speed adjustment of the header devices |
|
Automatic control of the central lubrication (time control) |
|
Grass feed |
Maize feed |
| LACOTEC Pick Up (from 2011) |
|
|
| Width of engagement |
2.75m |
|
| Maize headers |
|
4 – 6 rows |
| Mass and weights |
|
|
| Base machine |
2,900 kg |
| Width |
2,600 mm |
| Length (without header) |
1,150 mm |
| High performance |
5,700 mm |
| Height in the transport position |
3,950 mm |
| Driving power min. — max. |
147-367 KW (200-500 HP) |
| Speed of the power take off shaft |
900 U/min |
